Features
- Handles up to 20 liters (H2O) in a vessel
- High definition backlit LCD display
- Brushless shade motor
- 99hr 50min timer
- Ceramic coated Aluminum plate is adopted for minimizing heat loss and excellent resistance to chemical and scratches
- Low profile sleek design and easy to use jog dial for your stable and quick control of speed and temperature setting
- The product is furnished with functions capable of protecting the overheating, overcurrent, and sensor errors
- The mounting position for an external probe is also provided in the main unit of the product
Specifications
Material (Body)
Powder Coated Aluminum
Material (Plate)
Ceramic Coated Aluminum
Plate Size
180x180mm ; 7.09 inches x 7.09 inches
Stirrer Speed Range
80 to 1,500 rpm
Speed Control Resolution
5 rpm
Maximum Stirring Volume (H2O)
20Lit.
Heating Temperature
Max. 400℃
Temp Accuracy
±0.3℃
Controller
Digital Fuzzy Controller with Touch Button & Rotary Switch
Timer
99hr 59min
Display
Full Digital LCD Display with Back-Light Function
Heating Output
600 W
Motor Type
Brushless Shade Motor
Permissible Temp. & Humidity
5℃~40℃, <80%
Maximum Magnetic Stirrer Bar
50mm
Power Consumption
650W
Power
1 Phase, AC 120V, 60Hz or AC 230V, 50/60 HZ
Weight
4.6 kg
